Barebone ASUS NUC12 PRO i5-1250P 2xDDR4 M.2+2,5"
Built for Business. NUC 12 Pro
Boost business performance with 12th Gen Intel® Core™ processors and the latest features to support productivity, collaboration, and edge compute.
NUC 12 Pro Mini PCs, Kits, & Boards
Ready to work, wherever it’s needed—the 4x4 compact device is designed to go where you go, and fit into any space.
Surprising size. Supercharged performance
Level up your business with the latest technologies.
ASUS NUC 12 RNUC12WSHV500002I, UCFF, Mini PC barebone, DDR4-SDRAM, Ethernet LAN, Wi-Fi 6E (802.11ax)
- UCFF Black
- Built-in processor Intel i5-1250P
- 2 SO-DIMM Maximum internal memory: 64 GB DDR4-SDRAM
- SSD M.2
- On-board graphics card Intel Iris Xe Graphics
- Ethernet LAN Wi-Fi
| NUC 12 Pro Kit, Intel Core i5-1250P Processor (12M Cache | up to 4.40 GHz), Up to 64 GB dual-channel DDR4-3200 SODIMMs ASUS NUC 12 RNUC12WSHV500002I, UCFF, Mini PC barebone, DDR4-SDRAM, Ethernet LAN, Wi-Fi 6E (802.11ax) |
|
| Processor | |
|---|---|
| Processor manufacturer: | Intel |
| Processor family: | Intel® Core™ i5 |
| Processor generation: | 12th gen Intel® Core™ i5 |
| Processor model: | i5-1250P |
| Processor cores: | 12 |
| Processor threads: | 16 |
| Processor boost frequency: | 4.4 GHz |
| Performance cores: | 4 |
| Efficient cores: | 8 |
| Performance-core Max Turbo Frequency: | 4.4 GHz |
| Efficient-core Max Turbo Frequency: | 3.3 GHz |
| Built-in processor: | Yes |
| Processor cache: | 12 MB |
| Memory | |
|---|---|
| Memory slots type: | SO-DIMM |
| Number of memory slots: | 2 |
| Maximum internal memory: | 64 GB |
| Supported memory clock speeds: | 3200 MHz |
| Supported memory types: | DDR4-SDRAM |
| Memory voltage: | 1.2 V |
| ECC: | No |
| Storage | |
|---|---|
| Supported storage drive types: | SSD |
| Storage drive sizes supported: | M.2 |
| SSD form factor: | M.2 |
| NVMe: | Yes |
| Number of storage drives supported: | 2 |
| Graphics | |
|---|---|
| On-board graphics card: | Yes |
| Graphics card family: | Intel |
| On-board graphics card model: | Intel Iris Xe Graphics |
| Number of displays supported: | 4 |
| Performance | |
|---|---|
| Motherboard form factor: | UCFF |
| Number of processors supported: | 1 |
| Audio | |
|---|---|
| Built-in speaker(s): | No |
| Network | |
|---|---|
| Top Wi-Fi standard: | Wi-Fi 6E (802.11ax) |
| Wi-Fi standards: | Wi-Fi 6E (802.11ax) |
| WLAN controller model: | Intel Wi-Fi 6E AX211 |
| Ethernet LAN: | Yes |
| Wi-Fi: | Yes |
| LAN controller: | Intel I225-V |
| Bluetooth: | Yes |
| Bluetooth version: | 5.2 |
| Ports & interfaces | |
|---|---|
| USB 2.0 ports quantity: | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: | 3 |
| HDMI ports quantity: | 2 |
| HDMI version: | 2.1 |
| Combo headphone/mic port: | Yes |
| Ethernet LAN (RJ-45) ports: | 1 |
| Serial port via internal header: | No |
| Thunderbolt 4 ports quantity: | 2 |
| DC-in jack: | Yes |
| Expansion slots | |
|---|---|
| PCI Express slots version: | 4.0 |
| Design | |
|---|---|
| Chassis type: | UCFF |
| Product colour: | Black |
| Cooling type: | Active |
| On/off switch: | Yes |
| LED indicators: | Yes |
| VESA mounting: | Yes |
| Product type: | Mini PC barebone |
| Software | |
|---|---|
| Windows operating systems supported: | Windows 11 Home, Windows 11 Pro, Windows 10 Home, Windows 10 IoT Enterprise, Windows 10 Pro |
| Linux operating systems supported: | Yes |
| Power | |
|---|---|
| Power supply type: | External AC adapter |
| Weight & dimensions | |
|---|---|
| Width: | 117 mm |
| Depth: | 112 mm |
| Height: | 37 mm |
