Aflgjafi Seasonic 750W GC-750 ATX3.1 80+Gold

13519 13519 13519 13519 13519 13519 13519 13519 13519 13519 13519 13519 13519 13519
Aflgjafi Seasonic 750W GC-750 ATX3.1 80+Gold Aflgjafi Seasonic 750W GC-750 ATX3.1 80+Gold Aflgjafi Seasonic 750W GC-750 ATX3.1 80+Gold Aflgjafi Seasonic 750W GC-750 ATX3.1 80+Gold Aflgjafi Seasonic 750W GC-750 ATX3.1 80+Gold Aflgjafi Seasonic 750W GC-750 ATX3.1 80+Gold Aflgjafi Seasonic 750W GC-750 ATX3.1 80+Gold Aflgjafi Seasonic 750W GC-750 ATX3.1 80+Gold Aflgjafi Seasonic 750W GC-750 ATX3.1 80+Gold Aflgjafi Seasonic 750W GC-750 ATX3.1 80+Gold Aflgjafi Seasonic 750W GC-750 ATX3.1 80+Gold Aflgjafi Seasonic 750W GC-750 ATX3.1 80+Gold Aflgjafi Seasonic 750W GC-750 ATX3.1 80+Gold Aflgjafi Seasonic 750W GC-750 ATX3.1 80+Gold Seasonic CORE GC Series Unboxing | 80 PLUS Gold ATX 3.1 Power Supply
Framleiðandi: Seasonic
Framl.númer: SRP-CGC751-A5A32SF
Vörunúmer: 12946
Ekki til/Væntanleg

Seasonic GC-750 er traustur 750W aflgjafi frá framleiðanda sem hefur lengi verið í fremstu röð. Hann uppfyllir ATX 3.1 og PCIe 5.1 staðlana og fylgir honum innbyggður 12V-2x6 kapall, svo nýjustu skjákortin tengjast beint án millistykkis. Fyrir eldri kort eru tvö hefðbundin 8 pinna tengi. Með 80 Plus Gold nýtni helst hiti og rafmagnsnotkun í lágmarki, og 120 mm vifta með S2FC stýringu heldur vélinni hljóðlátri. Kaplarnir eru fastir svo engir kaplar týnast né fara á flakk.

Manual PDF
Upplýsingar frá framleiðanda
Fyrirspurn um vöru
Frí heimsending
Verð: 19.900 kr
Fá tilkynningu þegar varan lendir

Tæknilýsing

  • Framleiðandi: Seasonic
  • Gerð: CORE GC-750
  • Vörunúmer: SRP-CGC751-A5A32SF
  • Afl: 750W
  • Staðall: ATX 3.1 og PCIe 5.1
  • Nýtni: 80 Plus Gold
  • +12V lína: 62A (744W), ein lína
  • Kaplar: Fastir (ekki modular)
  • Móðurborðstengi: 1x 20+4 pinna ATX
  • Örgjörvatengi: 2x 4+4 pinna EPS
  • Skjákortstengi: 1x 12V-2x6 (allt að 600W), 2x 6+2 pinna PCIe
  • SATA tengi: 2
  • Molex tengi: 1
  • Vifta: 120 mm, HDB lega, S2FC viftustýring
  • Varnir: OCP, OPP, OTP, OVP, SCP, UVP
  • Inntaksspenna: 100–240V, 50/60Hz
  • Stærð: 140 x 150 x 86 mm
  • Litur: Svartur

CORE GC – Power Made Simple

The Seasonic CORE GC Series delivers reliable performance and modern ATX 3.1 compliance at an essential value. Designed for everyday builders and gamers, it embodies Seasonic’s trusted quality in a compact 140 mm design with a durable scratch-resistant finish.

With 80 PLUS® Gold efficiency, Smart and Silent Fan Control (S2FC), and a 120 mm HDB fan, it ensures cool, quiet, and stable operation. The CORE GC-750 and CORE GC-850 include a 12V-2×6 PCIe Gen 5.1 cable, ready for the latest GPUs, while the CORE GC-650 meets all ATX 3.1 requirements with traditional connectors.

Built on decades of engineering excellence, the CORE GC Series delivers the quiet efficiency, reliability, and durability that define every Seasonic power supply.

Next-Gen and Legacy GPU Cable
Includes native 12V-2x6 and 2× 8-pin cables for maximum compatibility

S2FC - Intelligent Fan Control Technology
The Smart and Silent Fan Control (S2FC) system intelligently regulates the power supply’s fan speed to achieve the ideal balance between cooling efficiency and silent operation. By dynamically adjusting the fan curve according to temperature, it ensures that your system remains quiet during low-to-medium usage and effectively cooled when performance demands increase.

Seasonic CORE GC-750 ATX 3.1, 750 W, 100 - 240 V, 50/60 Hz, 10 - 5 A, 100 W, 744 W

  •     750 W 100 - 240 V 50/60 Hz
  •     Motherboard power connector: 20+4 pin ATX
  •     PC ATX 80 PLUS Gold
  •     Active 12 cm
  •     Black
750 W, Gold, TBA, ATX/EPS, 0 - 40 °C, 100.000 hours
Seasonic CORE GC-750 ATX 3.1, 750 W, 100 - 240 V, 50/60 Hz, 10 - 5 A, 100 W, 744 W
  • 750 W 100 - 240 V 50/60 Hz
  • Motherboard power connector: 20+4 pin ATX
  • PC ATX 80 PLUS Gold
  • Active 12 cm
  • Black
Power
Total power:750 W
AC input voltage:100 - 240 V
AC input frequency:50/60 Hz
Input current:10 - 5 A
Combined power (+3.3V):100 W
Combined power (+12V):744 W
Combined power (+5V):100 W
Combined power (-12V):3.6 W
Combined power (+5Vsb):12.5 W
Max output current (+3.3V):20 A
Max output current (+12V):62 A
Max output current (+5V):20 A
Max output current (-12V):0.3 A
Max output current (+5Vsb):2.5 A
Power protection features:Over current, Over power, Under voltage, Over voltage, Short circuit, Overheating
Ports & interfaces
Motherboard power connector:20+4 pin ATX
Motherboard power cable length:55 cm
Number of SATA power connectors:2
SATA power cable length:600 mm
Peripheral (Molex) power connectors (4-pin):1
Peripheral (Molex) power cable length:600 mm
EPS power connector (8-pin):Yes
PCI Express power connectors (6+2 pin):2
PCI Express power cable length:55 cm
CPU power connector (4+4 pin):Yes
CPU power cable length:60 cm
ATX power connector (20+4 pin):Yes
PCI Express connector:Yes
Cabling type:Non-Modular
Performance
80 PLUS certification:80 PLUS Gold
Purpose:PC
Power supply unit (PSU) form factor:ATX
ATX version:3.1
Bearing technology:Ball bearing
Mean time between failures (MTBF):100000 h
Design
Product colour:Black
Cooling type:Active
Fan diameter:12 cm
Number of fans:1 fan(s)
On/off switch:Yes
Operational conditions
Operating temperature (T-T):0 - 40 °C
Operating relative humidity (H-H):15 - 65%
Packaging content
Cables included:AC
Certificates
Compliance certificates:CE, CB, China Compulsory Certification (CCC), cTUVus, BSMI, EAC, UKCA, RoHS, REACH, WEEE
Certification:CE, CB, CCC, cTUVus, TUV, BSMI, EAC, UKCA, Energy Star, RoHS, REACH, WEEE, ErP Lot 6
Weight & dimensions
Width:150 mm
Depth:140 mm
Height:86 mm
Packaging data
Package type:Box
Technical details
Sustainability certificates:ENERGY STAR, ErP
