Móðurborð 3647 Supermicro X11SPM-F DDR4 ECC
Major Benefits from Supermicro's in-house Design Superiority
Supermicro motherboard advantages:
- Technologically-advanced Motherboard Designs Since 1993
- Consistent highest-quality Design, Components, and Production Expertise
- Extensive Range of x86 Serverboards Available
- Competitive Price/Performance
- High Performance Boards Supporting the Latest CPU, memory, and add-on Hardware
- Standard Form Factors offer Feature - rich Support and application optimization
These competitive advantages help Supermicro maintain its design leadership in providing state-of-the-art motherboards for a wide range of applications. Always a step ahead of the competition, Supermicro is consistently first-to-market in delivering high-performance technology support. Offering the most extensive serverboard selection in the industry at competitive prices, Supermicro boards are quality-built to maximize customer satisfaction.
In addition, Supermicro also offers high-performance Embedded motherboards with product life cycles of up to 7 years.
| microATX, Intel Xeon Processor Scalable Family, AMI UEFI, ACPI 6.0, SMBIOS 3.0 or later Supermicro X11SPM-F, Intel, LGA 3647 (Socket P), 165 W, DDR4-SDRAM, 768 GB, 1.2 V |
|
| Processor | |
|---|---|
| Processor manufacturer: | Intel |
| Processor socket: | LGA 3647 (Socket P) |
| Processor number of cores supported: | 28 |
| Processor thermal power (max): | 165 W |
| Memory | |
|---|---|
| Supported memory types: | DDR4-SDRAM |
| Memory voltage: | 1.2 V |
| ECC: | Yes |
| Supported memory clock speeds: | 1600,1866,2133,2400,2666 MHz |
| Maximum internal memory: | 768 GB |
| Maximum RDIMM memory: | 192 GB |
| Storage controllers | |
|---|---|
| Supported storage drive interfaces: | SATA III |
| RAID support: | Yes |
| RAID levels: | 0, 1, 5, 10 |
| Graphics | |
|---|---|
| On-board graphics card model: | Aspeed AST2500 |
| Internal I/O | |
|---|---|
| USB 2.0 connectors: | 6 |
| Number of SATA III connectors: | 12 |
| TPM connector: | Yes |
| Rear panel I/O ports | |
|---|---|
| USB 2.0 ports quantity: | 6 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: | 5 |
| VGA (D-Sub) ports quantity: | 1 |
| COM ports quantity: | 2 |
| Network | |
|---|---|
| Ethernet LAN: | Yes |
| Wi-Fi: | No |
| Features | |
|---|---|
| Motherboard chipset: | Intel® C621 |
| Motherboard form factor: | micro ATX |
| Expansion slots | |
|---|---|
| PCI Express x16 (Gen 3.x) slots: | 2 |
| BIOS | |
|---|---|
| BIOS type: | UEFI AMI |
| ACPI version: | 6.0 |
| Processor special features | |
|---|---|
| Trusted Platform Module (TPM): | Yes |
| Operational conditions | |
|---|---|
| Storage temperature (T-T): | -20 - 60 °C |
| Operating temperature (T-T): | 0 - 60 °C |
| Operating relative humidity (H-H): | 10 - 85% |
| Storage relative humidity (H-H): | 10 - 95% |
| Logistics data | |
|---|---|
| Harmonized System (HS) code: | 84733020 |
| Weight & dimensions | |
|---|---|
| Width: | 243.8 mm |
| Depth: | 243.8 mm |
| Other features | |
|---|---|
| PCI Express x4 (Gen 3.x) slots: | 1 |
| PCI Express x8 (Gen 3.x) slots: | 1 |
| Supported DIMM module capacities: | 4GB, 8GB, 16GB, 32GB, 64GB, 128MB |
| Supported LRDIMM module capacity: | 32GB, 64GB |
| Supported LRDIMM clock speeds: | 1600,1866,2133,2400,2666 MHz |
| Maximum LRDIMM memory: | 384 GB |
| Supported RDIMM clock speeds: | 1600,1866,2133,2400,2666 MHz |
| Supported RDIMM module capacity: | 4GB, 8GB, 16GB, 32GB |
| Number of DIMM slots: | 6 |
| Number of processors supported: | 1 |
