ICY BOX IB-DK2245AC USB Type-C™ DockingStation with double video interface

Features
• Allows simultaneous 4K output via two video interfaces
- two DisplayPort™ interfaces up to 4096x2160@60 Hz or
- two HDMI® interfaces up to 4096x2160@60 Hz
• Supports the use of a 5K monitor with 2x DisplayPort™ cable
• Connection to a USB Type-C™ host computer with Power Delivery 60 W
• 2x USB Type-C™ and 4x USB 3.2 (Gen 1) Type-A interfaces Data transfer rates of up to 5 Gbit/s
• Gigabit LAN RJ45 interface with Wake-on-LAN function
• Audio input and audio output interfaces
• Provides an ON/OFF button to save energy and save resources
• Including external 100 W power supply (20V / 5 A)

Technical Data

• Model: IB-DK2245AC
• Article no.: 60658
• EAN code: 4250078170006
• Brand: ICY BOX
• Colour: Black
• Material: PC/ABS plastic
• Interface to host computer: USB 3.2 (Gen 1) Type-C™ / USB 3.0 Type-A
• Transfer rate: Up to 5 Gbit/s
• Output:
  • 2x DisplayPort™ 1.2, up to 4096x2160 @ 60 Hz
  • 2x HDMI® up to 4096x2160 @ 60 Hz
  • 4x USB 3.2 (Gen 1) Type-A up to 5 gbit/s (3x 5 V@0.9 A, 1x 5V @ 1.5 A BC 1.2)
  • 2x USB 3.2 (Gen 1) Type-C™ up to 5 Gbit/s (5 V @ 0.9 A)
  • 1x Gigabit LAN RJ45 with Wake-on-LAN function up to 10/100/1000 Mbit/s
  • 1x 3.5 mm microphone input
  • 1x 3.5 mm stereo audio output
• Power Delivery: Up to 60 W
• Resolution:
  • Dual mode: up to 2x 4096x2160 @ 60 Hz
  • Single mode: up to 1x 5120x2880 @ 60 Hz (connected via two DisplayPort® cables)
• ON/OFF button: Yes
• Kensington lock: Yes
• Length of cable: 100cm
• Power supply: External, AC 100-240 V / 2A, 50/60 hz, DC 20 V / 5A, 100 W Total power
• Operating system: Windows®, macOS®

System requirements
• Windows®, macOS®
• Installed DisplayLink™ drivers
• Power delivery via a Type-C™ host computer with PD support
• To use 4K/5K resolutions, appropriate 4K/5K monitors and DisplayPort™ 1.2 Support
is required
• The device is also compatible with Thunderbolt™ 3 Type-C™ computers

Packing content
1x IB-DK2245AC, 1x USB 3.2 (Gen 1) cable Type-C™ to Type-A,
1x USB 3.2 (Gen 1) cable Type-C™ to Type-C™, 1x power supply,
1x power cord, 1x manual
